Add a Spatially-Aware Compass

Source: R/annotation_compass.R
annotation_compass.Rd

`annotation_compass()` adds a compass (north arrow) to a ggplot map. It can align to **grid north** (top of the panel) or **true north** (geographic north). Styles are provided as grobs or functions returning grobs (for example `north_arrow_classic()`, `compass_sinan()`).

Usage

annotation_compass(
  mapping = NULL,
  data = NULL,
  ...,
  location = "bl",
  which_north = "grid",
  height = unit(1.5, "cm"),
  width = unit(1.5, "cm"),
  pad_x = unit(0.5, "cm"),
  pad_y = unit(0.5, "cm"),
  rotation = NULL,
  style = north_arrow_classic()
)

Arguments

mapping, data

Standard ggplot2 layer arguments (typically unused).

...

Additional parameters passed to the layer (rarely needed).

location

Character; one of `"tl"`, `"tr"`, `"bl"`, `"br"`, indicating top/bottom and left/right placement. Default: `"bl"`.

which_north

Character; `"grid"` (default) or `"true"`.

height, width

`grid::unit`. Compass box dimensions. Defaults: `1.5 cm`.

pad_x, pad_y

`grid::unit`. Padding from panel edges. Defaults: `0.5 cm`.

rotation

Numeric. Fixed rotation in degrees (counter-clockwise). When supplied, it overrides `"grid"` / `"true"` behavior.

style

A grob, `gList` / `gTree`, or a function returning a grob (for example `north_arrow_classic()`). Default: `north_arrow_classic()`.

Value

A ggplot2 layer object.

Details

* `"grid"` north: the compass points straight up in plotting space (no CRS required). * `"true"` north: the compass rotates toward the geographic North Pole using the plot CRS. This requires a valid CRS supplied by `coord_sf()` or injected via `layer$geom_params$crs`. * A fixed `rotation` (degrees counter-clockwise) always overrides the automatic `"grid"` / `"true"` logic. * The layer is annotation-like: it draws once per panel based on the panel bounds.

See also

[compass-styles]

Examples

nc <- sf::st_read(system.file("shape/nc.shp", package = "sf"), quiet = TRUE)

base <- ggplot() +
  geom_sf(data = nc, fill = "grey90") +
  theme_minimal()

# Example 1: Grid north (no CRS required), bottom-left
base + annotation_compass()


# Example 2: Custom style & position (top-left)
base + annotation_compass(location = "tl", style = compass_sinan())


# Example 3: True north (requires a CRS)
base +
  coord_sf(crs = "+proj=lcc +lon_0=-100 +lat_1=33 +lat_2=45") +
  annotation_compass(location = "br", which_north = "true")
